Horizontal MovementHD-7165

Horizontal MovementHD-7165
Product Description
12 KG grinding capacity
Inquiry
<span>Horizontal Movement</span><span>HD-7165</span>
Product Introduction



Grinding area



Grinding container (examples) :
詢價、詢問
Direct inquiry Put in the inquiry list 成功加入詢價單

  • Patented magnetic base design for left and right parallel movement, able to grind workpieces uniformly without dead corners.
  • Grinding area 900(L)x600(W)mm.
  • Can be equipped with enhanced grinding magnetic field (HD-7165F) Increased magnetic flux density 150-250%, effectively enhance grinding force & increases grinding heigh.
  • Suitable for long workpieces and flat workpieces.
  • Suitable for long biomedical tubes.
  • Suitable for large aluminum molds and aluminum shells.
MODEL DIMENSION(L X W X H) Max grinding area (LxW) POWER  WEIGHT
HD-7165  1360×1070×1365 mm  900×600mm 3 phase AC220/380V(50/60HZ) 281 KG

MODEL Max grinding capicity (reference) STANDARD ACCESSORIES
HD-7165  Stainless steel (Non-Magnetic), Copper  12 KG

1.Stainless pins/15 KG
2.Customized PP rectangular container : 1set
3. HD-765 round PP grinding container : 1set
4.Separating container : 1set
5.PIN collector : 2set
6.6. Grinding liquid (15,000c.c)
7. Operation manual
Stainless steel (Magnetic), Aluminum, Zinc, Iron, Steel 6 KG
